Specifikacija:

Tehnički opis

  • Zid od PVC-a, plav, iznutra gladak.
  • Ojačanje: bela čelična obloga obložena PVC-om.
  • Temperaturni opseg: -10 ° C do + 80 ° C.
  • Električna svojstva: neprovodljiva. Oba kraja spirale mogu biti izloženi i povezani na spojnice / fitinge, ako je potrebna provodljivost.

Spojnice / fitinzi

Standard: spajanje obujmicom.

Dodatne informacije

Tehnički podaci za radne uslove na temperaturi od 20 ° C.



ID (Unutrašnji prečnik)
[mm]

Debljina zidova
[mm]

Radni pritisak
[bar]

Maks. vakum
[bar]

Radijus savijanja
[mm]

Težina
[kg]

Dužina
[m]

20.0

0.5 ±0.03

1.9

0.55

20

0.11

10

25.0

0.5 ±0.03

1.7

0.45

25

0.15

10

30.0

0.5 ±0.03

1.6

0.40

30

0.22

10

32.0

0.5 ±0.03

1.5

0.35

32

0.22

10

35.0

0.5 ±0.03

1.4

0.30

35

0.22

10

40.0

0.5 ±0.03

1.4

0.30

40

0.28

10

45.0

0.5 ±0.03

1.3

0.30

45

0.26

10

50.0

0.5 ±0.03

1.3

0.28

50

0.29

10

51.0

0.5 ±0.03

1.3

0.28

51

0.30

10

60.0

0.5 ±0.03

1.1

0.25

60

0.50

10

63.0

0.5 ±0.03

1

0.25

63

0.54

10

65.0

0.5 ±0.03

1

0.25

65

0.56

10

70.0

0.5 ±0.03

1

0.25

70

0.56

10

75.0

0.5 ±0.03

0.8

0.20

75

0.63

10

76.0

0.5 ±0.03

0.8

0.20

76

0.65

10

80.0

0.5 ±0.03

0.8

0.18

80

0.70

10

90.0

0.5 ±0.03

0.7

0.15

90

0.76

10

100.0

0.6 ±0.03

0.6

0.15

100

0.79

10

102.0

0.6 ±0.03

0.6

0.15

102

0.82

10

110.0

0.6 ±0.03

0.5

0.14

110

0.84

10

120.0

0.6 ±0.03

0.4

0.13

120

0.85

10

125.0

0.6 ±0.03

0.4

0.12

125

0.98

10

130.0

0.6 ±0.03

0.4

0.12

130

0.98

10

140.0

0.6 ±0.03

0.3

0.12

140

1.05

10

150.0

0.6 ±0.03

0.25

0.10

150

1.18

10

160.0

0.75 ±0.03

0.25

0.10

160

1.35

10

180.0

0.75 ±0.03

0.2

0.10

180

1.48

10

200.0

0.75 ±0.03

0.2

0.09

200

1.69

10

203.0

0.75 ±0.03

0.2

0.09

203

1.70

10

250.0

0.8 ±0.03

0.12

0.08

250

2.10

10

300.0

0.8 ±0.03

0.1

0.06

300

2.52

10

350.0

0.8 ±0.03

0.1

0.03

350

2.93

10

400.0

1.0 ±0.03

0.08

0.02

400

3.39

5

500.0

1.0 ±0.03

0.06

0.01

500

4.10

5
